Audison APX 690 Features Horn Loaded Tweeter: 40 mm horn loaded dome tweeter contributing to its incredible efficiency of up to 96dB SPL. Acoustics lens applied to the tweeter, specifically designed to increase dispersion in the high frequency range. PEI (Polyethylene injected) supertweeter employed to strengthen emission of very high frequency ranges otherwise affected by off-axis positioning common to rear deck installations. Water-repellent treated paper cone, featuring a profile developed with FEM (Finite Element Method) simulation technology and optimized with the Klippel Scan Vibrometer. Pure copper mobile voice coil, wound on Kapton former, for better thermal and mechanical capacity. TPU (Thermoplastic Polyurethane) surround, featuring the exclusive shallow “Triple Wave” profile, for maximum excursion linearity. Polycotton spider material ensuring reliable performance and linear response to musical transients. Specifications Component: 3-way Coaxial Size mm (in.): Woofer; (6 x 9), Tweeter; 24 (0.9) Power Handling: Peak; 300W, Continuous (RMS); 100W Impedance: 4 Ohm Frequency Response: 40Hz – 23kHz Magnet size: mm (in.) 90 x 32 x 15; (3.54 x 1.26 x 0.59) Weight of one speaker: kg (lb); 1.225 (2.7) Woofer Voice Coil Ø: mm (in.) 25 (1) Tweeter Voice Coil Ø: mm (in.) 20 (0.78) ELECTRO-ACOUSTIC PARAMETERS D: 171mm Xmax: ±3.5mm Re: 3.2O Fs: 60Hz Le: 0.2mH Vas: 36L Mms: 16.6g Cms: 0.5mm/N BL: 5.3Tm Qts: 0.6 Qes: .7 Qms: 6.7 Spl: 96dB
Make sure this fitsby entering your model number.
Bullet Point 1: Audison 6X9 3-Way Full-Range Speaker
